Ray Tracer

CS426 Assignment 5

Assigned Nov. 23, 1998, due Sunday Dec. 13, 1998, 11:59pm

Last modified: Fri Dec 4 22:25:15 EST 1998

Introduction

In this assignment you will implement a basic raytracer. Use a recursive approach, as suggested in paragraph 6.10.1 of the Angel book.

Your program will read Inventor scene files and support:

triangles and spheres
materials (with reflections and transparency)
directional-, point- and spotlights
jittered oversampling

Note that you have to work with a different partner from the one you worked with on assignment 4. Send us e-mail when you've found a partner, or when you have trouble finding one.

Scene geometry

Read your scenes from an Inventor file, then traverse the resulting scenegraph and convert it to whatever datastructure you want to use. Note that you need to support only a few Inventor nodes (SoIndexedFaceSet, SoSphere, SoMaterial, SoDirectionalLight, SoPointLight, SoSpotLight, SoPerspectiveCamera, ...).

Reading

The lecture notes of lecture 6 describe lighting models, and the notes of lecture 11 explain ray tracing. The notes of lecture 12 deal with some of the extra credit options.

Similarly, paragraphs 6.1-6.5 of the Angel book talk about shading, and paragraph 6.10.1 talks a little about ray tracers.

Implementation notes

General

Pay careful attention to this quote:

Novice programmers often neglect the design phase, instead diving into coding without giving thought to the evolution of a piece of software over time. The result is a haphazard, poorly modularized code which is difficult to maintain and modify. A few minutes of planning short-term and long-term goals at the beginning is time well spent.
- Paul Heckbert, ``Writing a Ray Tracer,'' in An Introduction to Ray Tracing, edited by Andrew Glassner (Note that this book is an excellent reference for all sorts of ray tracing techniques)

You should think very carefully about the structure of your system. You need to intersect rays with triangles, spheres, and possibly with your acceleration structures. You want some kind of generic object with function pointers to the intersection functions (in C++ you would use inheritance with virtual functions). Start early, and you've got plenty of time to finish.

Specific

you can use PPM as your output file format (preferably the "P6" version) (run man ppm). It's probably a good idea to represent all RGB intensities as floats between 0.0 and 1.0, and convert to the 0-255 range just before writing the ppm file.
let the user set the trace depth (at which the recursion terminates), and also terminate when the contribution of a ray becomes too small
do not use SoRayPickAction
you may use SoGetBoundingBoxAction to compute bounding boxes of shapes
use the shininess field of an SoMaterial node to compute the contribution of a reflected ray

use the SoInfo node to pass "non-Inventor" information to your raytracer. Identify the information by the node name. Put the actual values in the string field. For some parameters we'll specify the required node name and value format (so we can run our and other's input files on your ray tracer):

Nodename Description Value type Default value

IOR index of refraction, every transparent object after this node has this index of refraction float 1.5

TRACEDEPTH maximum ray tracing recursion level (first level = 0) integer 4

IMAGEWIDTH output image width in number of pixels. Compute the height from the camera's aspect ratio integer 400

IMAGEHEIGHT output image height in number of pixels. Compute the width from the camera's aspect ratio. If both IMAGEWIDTH and IMAGEHEIGHT are specified, ignore the camera's aspect ratio, and use IMAGEWIDTH/IMAGEHEIGHT instead integer (none)

you just need to support a perspective camera
be careful with your memory management: make sure you delete rays once you're done with them. In any case it is useful to gather statistics, for example on the number of rays fired, number of intersections computed, etc.

Nodename	Description	Value type	Default value
IOR	index of refraction, every transparent object after this node has this index of refraction	float	1.5
TRACEDEPTH	maximum ray tracing recursion level (first level = 0)	integer	4
IMAGEWIDTH	output image width in number of pixels. Compute the height from the camera's aspect ratio	integer	400
IMAGEHEIGHT	output image height in number of pixels. Compute the width from the camera's aspect ratio. If both IMAGEWIDTH and IMAGEHEIGHT are specified, ignore the camera's aspect ratio, and use IMAGEWIDTH/IMAGEHEIGHT instead	integer	(none)

What to submit

Source, makefile, Inventor scenefiles from both your fourth assignments, and a writeup, containing:

a cool name for your raytracer
the names of you and your partner (you can run submit from either account)
a list of the features you implemented
explanations for the extra credit features you implemented (also see the "Grading" section below)

Do not submit image files. Instead, put a URL in your writeup.html pointing to a page with ray-traced images of the files from the 4th assignment, and images showing off your extra features.

Grading

If you implement all the required features, you'll score 14 out of 20 points. A number of extra credit options are listed below. The ones we think are the easiest are marked with a

Many more are possible. Foley & van Dam, paragraph 16.12 is a good source for ideas. Also see the next section for pointers to extra credit ideas.

Feature	Value
The winning digit "2" for the art contest	2 points
Non-winning digit "2" (if it's pretty :-)	1 point
Cones and cylinders	1 point
Constructive solid geometry (Foley & van Dam, 12.7)	3 points
Area lights, soft shadows	1 point
A user interface which shows the ray tracing in progress, showing a coarse picture quickly, becoming progressively finer	1 point
Adaptive oversampling using a priority queue, displaying intermediate results in real-time (Foley & van Dam, 15.10.4)	2 points
Motion blur (of animated objects) (Foley & van Dam, 16.10)	2 points
Depth of field (Foley & van Dam, 16.10)	1 point
Real camera lenses (see this SIGGRAPH paper (in PDF format) for more info)	2 points
Texture mapping	1 point
Texture antialiasing using mip-mapping	1 point
Bump mapping	1 point
Procedural textures (checkerboard, wood, marble, wavy water, etc.)	2 points
Environment mapping (Foley & van Dam, 16.6)	2 points
Bounding volumes	1 point
Hierarchical bounding volumes	2 points
Octree (Foley & van Dam, 12.6.3)	2 points
BSP tree (Foley & van Dam, 12.6.4)	4 points
Intersections with actual curved surfaces (e.g. tensor product surface, extrusion)(use a root finding method, and explain in your writeup why your method converges and is correct)	3 points
Parallelize your raytracer, using one master and several "compute slaves". Make sure your system is nicely load-balanced.	2 points

Finally...

There is an enormous amount of info on raytracing on the web. The POVRAY site is a good starting point. Or take a look at the Ray Tracing News magazine. Not to mention the SIGGRAPH proceedings...

Check out these images:

pocketwatch (from the POVRAY site)
LEGO train station (from this site)
Glasses (from this site)
old ray tracing assignment image (Fall 1995)

CS426, CS Department, Princeton University
